Up to now: rows, chains, stacks, hash tables. All of them have a fixed connection pattern. The most general data structure has no fixed pattern at all: just nodes that point to other nodes, in any topology you like. We call it a graph. When the graph has no cycles and a single root, we call it a tree. When the graph is undirected, finite, and connected, we still call it a graph. The two names refer to the same idea at different shapes.
Once you can see graphs, you see them everywhere. The web is a graph (pages linking to pages). Your filesystem is a tree. Your social network is a graph. The dependency tree of a build system is a tree. The transformer's computation graph is a graph. Phase 7's whole world is, structurally, graphs.
The vocabulary
- Node (also vertex): one of the things being connected.
- Edge: a connection between two nodes.
- Directed: edges have a direction (A → B is not the same as B → A). The web is directed.
- Undirected: edges go both ways. Friendship in a social network (mostly).
- Weighted: each edge has a number — distance, cost, probability.
- Tree: a connected graph with no cycles. Each child has exactly one parent.
- Binary tree: each node has at most two children.
- DAG (directed acyclic graph): directed, no cycles. Build dependency graphs, autograd graphs.
Two ways to represent
Adjacency list
Each node has a list of its neighbours. The standard.
std::vector<std::vector<int>> graph(N);
graph[0].push_back(1); // edge 0 -> 1
graph[0].push_back(2); // edge 0 -> 2
graph[1].push_back(3); // edge 1 -> 3
// to visit all neighbours of node n:
for (int m : graph[n]) { visit(m); }Memory: O(V + E), where V is the number of vertices and E the edges. Best for sparse graphs (most graphs are sparse).
Adjacency matrix
An N×N grid; matrix[i][j] = 1 if there's an edge from i to j.
Memory: O(V²). Faster lookup ("is there an edge?") in O(1). Used for very dense graphs and for some algorithms (Floyd-Warshall) that need quick edge queries.
The two algorithms you must know
Depth-First Search (DFS)
Walk as deep as you can, backtrack when stuck. Implemented with recursion (or an explicit stack):
void dfs(int n, std::vector<bool>& visited) {
if (visited[n]) return;
visited[n] = true;
visit(n);
for (int m : graph[n]) dfs(m, visited);
}Used for: cycle detection, topological sort, finding connected components, solving mazes.
Breadth-First Search (BFS)
Explore by distance from the source. Uses a queue:
void bfs(int start) {
std::queue<int> q;
std::vector<bool> visited(graph.size(), false);
q.push(start); visited[start] = true;
while (!q.empty()) {
int n = q.front(); q.pop();
visit(n);
for (int m : graph[n]) {
if (!visited[m]) {
visited[m] = true;
q.push(m);
}
}
}
}Used for: shortest path on unweighted graphs, level-order tree traversal, web crawling. Dijkstra's algorithm is BFS with a priority queue instead of a regular queue, generalising to weighted graphs.
Trees you'll meet
- Binary search tree — sorted; lookup/insert in O(log n) when balanced.
std::mapis one (red-black variant). - Heap — a tree where parent > children. Used by priority queues (Week 35).
- Trie — a tree of characters; great for autocomplete and dictionary-based games (Scrabble — Week 39!).
- Quad-tree / oct-tree — spatial subdivision for 2D/3D collision detection and rendering.
- B-tree — wide branching, designed for disk pages. Every database index is one of these.
Why this matters for AI
The autograd "computation graph" inside PyTorch is a directed acyclic graph: each tensor operation is a node, the inputs are edges. To compute gradients, you walk the graph backwards (a topological sort + DFS). Without graphs as a concept, modern deep learning is unimaginable.
Game-tree search — Minimax, Alpha-Beta — is a tree traversal. Phase 5's chess AI lives entirely in that algorithmic family.
Knowledge graphs, retrieval-augmented generation, the relationship between attention heads — all graphs. After this week, every "X is connected to Y" relationship in the AI literature should look like a familiar shape.
Phase 4 is done. You now have the data structures and the analysis tools. The rest of the course is about putting them to work.
Try it yourself
- Build a small adjacency-list graph of cities and roads. Implement BFS to find the shortest path (in number of hops) between two cities.
- Implement a binary search tree. Add a few values. Walk it in-order; confirm the values come out sorted.
- Skim the Wikipedia page for "graph data structure" and notice how many specific algorithms exist for graph problems. There's a whole field.
What's next — and welcome to Phase 5
You now have the language (C/C++), the abstractions (OO), and the toolbox (data structures and algorithms). Time to actually build something.
Phase 5 — The Builds — is three games, each ending with an AI opponent. Tic-Tac-Toe → Scrabble → Chess. By the end of Phase 5 you'll have written 5,000 lines of working C++ that plays games — and the AI techniques you'll learn there are more or less the same ones that won AlphaGo.
Week 37 is Project 1 — Tic-Tac-Toe.
